Stove & fireplace insert & enclosure

Product Brief Description: BW vermiculite fire bricks : Though the working temperature of stoves & fireplaces is not high, but due to the uneven heating, the fireproof brickss are easily getting bending, cracking. It is a big problem which confus...

Product Brief Description:

BW vermiculite fire bricks : Though the working temperature of stoves & fireplaces is not high, but due to the uneven heating, the fireproof brickss are easily getting bending, cracking. It is a big problem which confusing the stoves & fireplaces manufacturers.

Key Features:

BW vermiculite fire brick can resist 1,100 ℃ fire heating, the reheat linear shrinkage is <1%.

In real fire stoves applying testing, diagonal length of 1000 mm bending less than 2 mm, which is almost no bending.

Anymore, it is light-weight(0.6-1.0 g/cm3), good strength which can be cut, sawed, punched etc. processing by wood-tools.

Excellent insulation performance and no need to worry about the pulverization

Parameter Specification:

Maximum service temperature	1100℃	1200℃	1200℃	1200℃
Density (Kgs/m3）	600 kg/m³	700 kg/m³	800 kg/m³	900 kg/m³
Compressive strength	4.0 Mpa	4.5 Mpa	5.5 Mpa	6.2 Mpa
Bending strength	1.5 Mpa	2.0 Mpa	2.1 Mpa	2.2 Mpa
Linear reheat shrinkage	1.5%	1.0%	1.0%	1.0%
Thermal conductivity
Mean temp.：@ 200℃	0.13 W/(m*K)	0.14 W/(m*K)	0.16 W/(m*K)	0.18 W/(m*K)
Mean temp.：@ 400℃	0.15 W/(m*K)	0.16 W/(m*K)	0.18 W/(m*K)	0.20 W/(m*K)
Mean temp.：@ 600℃	0.17 W/(m*K)	0.18 W/(m*K)	0.20 W/(m*K)	0.22 W/(m*K)
Mean temp.：@ 800℃	0.19 W/(m*K)	0.20 W/(m*K)	0.22 W/(m*K)	0.25 W/(m*K)
